Description
Product Name: Polyvinylidene Fluoride PVDF CIDP02 – Solar PV Backsheet
CAS: 24937-79-9
Grade: Solar PV Backsheet Grade （CIDP02）
Packages: 20kg/anti-static bag/carton or cardboard drum
Main use: used as solar cell (photovoltaic) backsheets
Availability : In Stock
What is PVDF (CIDP02) ?
PVDF (CIDP02) is an outdoor material with the best comprehensive performance among fluoropolymers. It has a high melt index, good mechanical strength and toughness. The resin has excellent acid and alkali resistance, excellent heat resistance, and high mechanical strength. And abrasion resistance, especially with excellent weather resistance. It is suitable for the preparation of PVDF membrane materials through the dissolution casting process.
PVDF (CIDP02) is widely used in solar cell (photovoltaic) backsheets. Solar backsheets generally have a three-layer structre (PVDF/PET/PVDF), and the outer protective layer PVDF has good resistance to environmental corrosion.
Certificate of Analysis
| Component | Test Method | Specification |
| Appearance | Eye-measurement | White power, not lump |
| Moisture Content, % | GB/T11133-2015 | ≦0.10 |
| Melting Point, ℃ | ASTM D3418-15 | 165~175 |
| Relative Density | GB/T1033.1-2008 Method A |
1.77~1.79 |
| Melt Mass-flow Rate MFR/(g/10min) | GB/T 3682-2000, 230℃, 5kg | 8.0~30.0 |
| Tensile Strength/Mpa | GB/T 1040.1-2006 | ≧25 |
| Elongation at Break, % | GB/T 1040.1-2006 | ≧20 |
| Hardness | GB/T 2411-2008 | ≧70 |
To conduct our commitment of being a reliable partner to offer solutions when you need Isotope gases. Visit www.asiaisotopeintl.com for more information or call us for a in-time communications.
What are applications of PVDF (CIDP02) ?
PVDF (CIDP02) is widely used in solar cell (photovoltaic) backsheets. Solar backsheets generally have a three-layer structre (PVDF/PET/PVDF), and the outer protective layer PVDF has good resistance to environmental corrosion.
